12V 30Ah LiFePO4 Battery Pack
- High temperature charging or discharging cut-off.
- Overcharging and discharging protection.
- Over current and short circuit protection.
- Battery cells auto balance.
- Max charge current: 8A*
- Max discharge current: 8A*
* C/D Current can be customized.
Features
1) Long cycle life, lightweight battery, no voltage memory effect, high safety performance, environment friendly
2) Built-in BMS system, with multiple protection functions, protection system (PCM / BMS)
3) High capacity, high storage energy density
4) Long service life, under normal conditions, the lifepo4 battery charge-discharge cycle can be more than 2000 times.
Applications
- Solar streetlights
- integrated solar streetlights
- LED outdoor lights
- landscape light, garden lights
- pole lights, light boxes
- LED billboards
- wireless monitoring equipment
- mining
- medical equipment
- machinery and equipment, instrumentation
- communications equipment, communications base station
- Emergency Lights
This Lithium Iron Phosphate Battery Pack 12.8V 30Ah comes with 5 Years Limited Warranty.
This battery is specially designed for Semi Integrated Solar Street Light and other Solar energy storage applications.
Battery Management System(BMS) is included for protection of the battery from Short circuits, Over current, Over charge, and Over-discharge BMS also provides a battery balancing feature.
The battery is customizable as per customer requirements.
Warranty
Specification
| Battery Model | 12V30Ah |
| Cell Capacity | 3.2V | 6.0Ah |
| Type of cell | Cylindrical LFP 32650 |
| Nominal Capacity | 30.0Ah |
| Nominal Voltage | 12.8V |
| Voltage Range | 10.5V – 14.6V |
| Total Energy | 384Wh |
| Configuration | 4S5P |
| Rated Charging Current | 5A |
| Max. Charge Current | 8A |
| Rated Discharge Current | 5A |
| Max. Discharge Current | 10A |
| Discharge Cutoff Voltage | 10.5V |
| Maximum Pulse Discharge Current | 15A for 5 Sec |
| Cycle Life | ≥2000 Cycle |
| Operating Temperature Range @ Discharging | 0á´¼ to +55á´¼C |
| Storage Temp Range | 30á´¼ to +45á´¼C |
| Long Term Storage Temp Range | 5á´¼ to 25á´¼C |
| Case Matterial | Soft Packing |
| IP Class | ------ |
| Weight | 1.32kg (approx.) |
| Dimension (l*b*h)±3mmb | (1) 92 *90*361mm
(2)Â 75*108*388mm |
| |
Datasheet
Download the datasheet for the battery
